Description

AVC793 4CH H.264 Real-Time Network DVR

Description
The AVC793 4CH H.264 Real-Time Network DVR provides comprehensive surveillance solutions with a range of advanced features. Utilizing H.264 video compression technology, it offers efficient and high-quality video recording. The DVR is controlled via a USB mouse with a user-friendly GUI OSD (On-Screen Display) for easy navigation and setup. The DVR/Camera Communication System (DCCS) ensures seamless integration with connected cameras. Intelligent motion-triggered recording enhances security by activating recording only when movement is detected. It supports remote surveillance, allowing for full independent operation from anywhere. Multiplex functionality allows for simultaneous live display, recording, playback, backup, and network operations. The system also features motion detection with 16 × 12 grids per channel and adjustable sensitivity for precise alerts, event notifications via FTP and email, IR remote control, PTZ control, and password protection. The DVR also includes video loss detection and supports customizable camera titles and date formats.

Features

• H.264 Video Compression Technology for efficient and high-quality video recording
• USB Mouse Control with user-friendly GUI OSD for easy operation and setup
• DVR/Camera Communication System (DCCS) for seamless camera integration
• Intelligent Motion-Triggered Recording activates only when movement is detected
• Remote Surveillance capability for full independent operation from anywhere
• Multiplex Operation supports simultaneous live display, recording, playback, backup and network functions
• Motion Detection with 16 × 12 grids per channel and adjustable sensitivity
• Event Notification via FTP and email
• IR Remote Control included
• PTZ Control supported
• Key Lock with password protection
• Video Loss Detection with alerts
• Customizable Camera Title (up to 6 letters)
• Multiple Date Display Formats (YY/MM/DD, DD/MM/YY, MM/DD/YY)
• Auto Recovery after power failure

Specifications

• Model: AVC793
• Hard Disk Storage: 1 SATA HDD (up to 2TB)
• Quick Search: Time / Motion / Alarm search modes
• SATA Interface: Built-in
• Recording Modes: Manual, Timer, Motion, Alarm, Remote
• USB Mouse Control: Yes
• Motion Detection Sensitivity: 4 adjustable parameters
• IR Remote Control: Yes
• PTZ Control: Yes
• Key Lock (Password Protection): Yes
• Video Loss Detection: Yes
