Name: Dahua IPC-HDBW2831R-ZAS-S2 8MP 4K Lite IR Vari-Focal Dome Network Camera
Brand: Dahua
SKU: IPC-HDBW2831R-ZAS-S2
Availability: InStock

Dahua IPC-HDBW2831R-ZAS-S2 8MP 4K Lite IR Vari-Focal Dome Network Camera

Dahua IPC-HDBW2831R-ZAS-S2 8MP 4K Lite IR Vari-Focal Dome Network Camera

£280.12

Availability: 5 in stock SKU: IPC-HDBW2831R-ZAS-S2 Category: CCTV Brand: Dahua

Dahua IPC-HDBW2831R-ZAS-S2 8MP 4K Lite dome IP camera with IR night vision, starlight technology, PoE, and intelligent video analytics.

Description
Technical Specification

Description

The Dahua IPC-HDBW2831R-ZAS-S2 8MP 4K Lite Dome Network Camera delivers superior video performance and advanced surveillance features for professional security applications. Powered by a 1/2.7″ CMOS image sensor, it provides crisp 4K ultra-high-definition footage at up to 15fps and smooth 2688×1520 resolution at 25/30fps.

Equipped with Smart H.265/H.264 compression technology, the camera reduces bandwidth and storage needs without compromising video quality. Its built-in IR LEDs deliver up to 40m night vision, while starlight technology ensures clear, vibrant images even in low-light environments.

With support for intelligent video analytics (IVS) including tripwire and intrusion detection, plus abnormality alarms such as motion detection, tampering, and SD card errors, this camera enhances security monitoring and response efficiency.

The robust IP67 weatherproof and IK10 vandal-resistant housing makes it ideal for both indoor and outdoor installations. Power options include 12V DC or PoE for flexible setup. Additional features include audio I/O, alarm I/O, Micro SD card support (up to 256GB), WDR, 3D DNR, BLC, and HLC for superior adaptability across environments.

Key Features

Ultra HD Clarity – 8MP resolution (3840×2160) for sharp 4K surveillance footage
Starlight Technology – Clear, full-color images in low-light conditions
IR Night Vision – Built-in LEDs with up to 40m range for 24/7 security
Smart Video Compression – H.265/H.264 codecs for reduced storage use
Intelligent Analytics (IVS) – Intrusion, tripwire, and tamper detection
Rugged Build – IP67 weatherproof and IK10 vandal-resistant housing
Flexible Storage & Power – Micro SD up to 256GB, 12V DC/PoE support
Advanced Image Functions – WDR, 3D DNR, HLC, BLC, digital watermarking

Applications

Commercial and residential building surveillance
Outdoor monitoring in car parks, campuses, and retail areas
High-security environments requiring vandal-resistant cameras
Nighttime monitoring in low-light locations
Integration with ONVIF-compliant NVRs and VMS platforms

Camera

Image Sensor

1/2.7” 8Megapixel progressive CMOS

Effective Pixels

3840 (H) × 2160 (V)

ROM

128 MB

RAM

256 MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100,000 s

Min. Illumination

0.008 Lux@F1.5

IR Distance

40 m (131.2 ft)

IR On/Off Control

Auto/Manual

IR LEDs Number

Pan/Tilt/Rotation Range

Pan: 0°–355°Tilt: 0°–67°

Rotation: 0°–355°

Lens

Lens Type

Motorized vari-focal

Mount Type

φ14

Focal Length

2.7 mm–13.5 mm

Max. Aperture

F1.5

Field of View

Pan: 113°–31°Tilt: 58°–17°

Diagonal: 138°–36°

Iris Type

Fixed

Close Focus Distance

0.8m–0.8m (2.62 ft–2.62 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

85.3 m(279.9 ft)

34.1 m(111.9 ft)

17 m(55.8 ft)

8.5 m(27.9 ft)

280 m(918.6 ft)

112 m(367.5 ft)

56 m(183.7 ft)

28 m(91.9 ft)

Smart Event

General IVS Analytics

Tripwire; intrusion

Video

Video Compression

H.265; H.264; H.264B; MJPEG

Smart Codec

Yes

Video Frame Rate

Main stream:3840 × 2160 (1 fps–15 fps)

2688 × 1520 (1 fps–25/30 fps)

Sub stream:

704 × 576 (1 fps–25 fps)

704 × 480 (1 fps–30 fps)

Stream Capability

2 streams

Resolution

3840 × 2160 (3840 × 2160); 3072 × 2048 (3072 × 2048); 3072 ×1728 (3072 × 1728); 2592 × 1944 (2592 × 1944); 2688 × 1520 (2688 × 1520); 3M (2048 × 1536); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)

Bit Rate Control

CBR/VBR

Video Bit Rate

H.264: 32 Kbps–8192 KbpsH.265: 12 Kbps–8192 Kbps

Day/Night

Auto(ICR)/Color/B/W

BLC

Yes

HLC

Yes

WDR

120 dB

White Balance

Auto/natural/street lamp/outdoor/manual/regional custom

Gain Control

Auto/Manual

Noise Reduction

3D DNR

Motion Detection

OFF/ON (4 areas, rectangular)

Region of Interest(RoI)

Yes (4 areas)

Smart IR

Yes

Image Rotation

0°/90°/180°/270° (Supports 90°/270° with 2688 × 1520 resolution and lower.)

Mirror

Yes

Privacy Masking

4 areas

Audio

Audio Compression

G.711a; G.711Mu; G.726; AAC

Network

RJ-45 (10/100 Base-T)

Protocol

IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; Bonjour

Interoperability

ONVIF(Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec

User/Host

Edge Storage

Cloud; FTP; SFTP; Micro SD Card (support max. 256 GB); NAS

Browser

IEChrome

Firefox

Management Software

Smart PSS; DSS; DMSS

Mobile Phone

IOS; Android

Certification

Certifications

CE-LVD: EN60950-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07

Port

Audio Input

1 channel (RAC port)

Audio Output

1 channel (RAC port)

Alarm Input

1 channel In: 5mA 5V DC

Alarm Output

1 channel Out: 300mA 12V DC

Power

Power Supply

12V DC/PoE (802.3af)
