Hikvision iDS-7208HQHI-M1/XT 8CH 1080p DVR – AcuSense, H.265, Facial Recognition, 5-in-1
£223.00
Hikvision iDS-7208HQHI-M1/XT is an advanced 8CH AcuSense DVR supporting facial recognition, perimeter protection, H.265 Pro+ compression, and up to 12 IP cameras.
- Description
- Technical Specification
Description
The Hikvision iDS-7208HQHI-M1/XT is a high-performance 8-channel hybrid DVR designed for professional-grade surveillance systems. Equipped with AcuSense technology, it supports facial recognition, perimeter protection, and AcuSearch, powered by a deep learning algorithm for intelligent, real-time threat detection and post-event analysis.
This 1U DVR supports input from HDTVI, AHD, CVI, CVBS, and IP formats, allowing for flexible system expansion and mixed camera installations. It can handle up to 12 IP channels in total and offers encoding up to 3K/5MP Lite @ 12fps for sharp and detailed recording.
Using efficient H.265 Pro+ compression, the DVR maximises storage space while maintaining video quality. Additional features include two-way audio over HDTVI, full-channel motion detection, and AcuSearch technology for quick and accurate event searches.
Whether you’re protecting residential, retail, or commercial premises, this DVR delivers powerful, AI-driven surveillance in a compact, efficient design.
Key Features
- 8CH AcuSense DVR with 5-in-1 signal input
- Supports 2CH facial recognition or 4CH perimeter protection
- 4CH AcuSearch smart playback
- Encoding up to 3K/5MP Lite @ 12fps
- H.265 Pro+ compression for enhanced storage efficiency
- Motion detection on all channels
- HDTVI two-way audio supported on all channels
- Up to 12 IP camera input channels
- 1 SATA HDD bay (up to 10TB capacity)
- Deep learning algorithm for accurate threat analysis
Applications
- Advanced commercial or industrial security systems
- AI-driven smart surveillance setups
- Systems requiring facial recognition or line-crossing detection
- Hybrid analogue/IP CCTV installations
- Facial Recognition
- Face Picture LibraryUp to 16 face picture libraries
- Face Picture Comparison (Captured from Camera)Face picture comparison, face picture search (2-ch face picture comparison alarm for HD analog camera)
- Motion Detection 2.0
- Human/Vehicle Analysis
Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;
Quick search by object or event type is supported;
- Perimeter Protection
- Human/Vehicle Analysis
Up to 4-ch
Note: Face picture comparison, motion detection 2.0 and perimeter protection cannot be enabled at the same time. Enable one function will make the other two unavailable.
- Video and Audio
- IP Video Input4-ch (up to 12-ch), Up to 6 MP resolution
- Analog Video Input
8-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
- HDTVI Input3K(2960 x 1665)@25/20 fps, 3K(3328×1504)@20fps,5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
- AHD Input5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
- HDCVI Input3K(2880×1620)@25fps, 5MP(2592 × 1944)@20 fps, 4MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
- CVBS InputPAL/NTSC
- HDMI Output
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,
HDMI/VGA simultaneous output
- VGA Output
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,
HDMI/VGA simultaneous output
- CVBS Output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
- Audio Input8-ch, RCA (2.0 Vp-p, 1 KΩ), 8-ch via coaxial cable;4-ch, RCA (2.0 Vp-p, 1 KΩ), 8-ch via coaxial cable;1-ch (up to 8-ch is optional), RCA (2.0 Vp-p, 1 KΩ),8-ch via coaxial cable
- Audio Output1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
- Synchronous playback8-ch
- Recording
- Video CompressionH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
- Encoding Resolution
When 1080p Lite mode is not enabled:
3K lite/5 MP lite/4 MP lite/1080p/720p/VGA/WD1/4CIF/CIF;
When 1080p Lite mode is enabled:
3K lite/5 MP lite/4 MP lite/1080p lite/720p lite/VGA/WD1/4CIF/CIF
- Frame Rate
Main stream:
When 1080p Lite mode not enabled:
For 3K stream access: 3K lite@12fps;4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@20fps
For 5 MP stream access: 5 MP lite@12fps;4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@20fps
For 4 MP stream access: 4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
For 1080p stream access: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
When 1080p Lite mode enabled:
3K lite/5 MP lite@12fps;4 MP lite@15fps;1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
Sub-stream:
WD1/4CIF@12fps; CIF@25fps (P)/30fps (N)
- Video Bitrate32 Kbps to 6 Mbps
- Dual-streamSupport main stream or sub stream
- Stream TypeVideo, Video & Audio
- Audio CompressionG.711u
- Audio Bitrate64 Kbps
- Network
- Remote Connection64
- Total Bandwidth96 Mbps
- Network ProtocolTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
- Network Interface1, RJ45 10/100 Mbps self-adaptive Ethernet interface
- Wi-FiConnectable to Wi-Fi network by Wi-Fi dongle through USB interface
- Auxiliary Interface
- Serial InterfaceRS-485 (half-duplex)
- SATA1 SATA interface, up to 10 TB capacity for each disk
- Alarm In/Out8/4;N/A (optional to support);4/1
- USB Interface
Front panel: 1 × USB 2.0;
Rear panel: 1 × USB 2.0
- General
- Power Supply12 VDC, 1.5 A
- Consumption≤ 18 W (without HDD)
- Working Temperature-10 °C to + 55 °C (14 °F to 131 °F)
- Working Humidity10% to 90%
- Dimension (W × D × H)319 × 236 × 48 mm (12.6 × 9.3 × 1.9 inch)
- ≤ 1.78 kg (3.9 lb) (without HDD)
