| OPERATIONAL |
|
| Video Standard |
NTSC/PAL |
| Scanning System |
Progressive |
| Image Sensor |
HC30WB5r3: 1/2.9” Progressive CMOS |
| Number Of Pixels (H × V) |
HC30WE5R3: 1/2.7” Progressive CMOS |
| Minimum Illumination |
HC30WE5R3: 0.03 lux color @ F2.0, 0 lux
B/W with IR LEDs on @ F2.0 |
| S/N Ratio |
> 55 dB |
| Electronic Shutter Speed |
1/5 ~ 1/32,000 |
| IR Distance |
Distance up to 50m(165ft) |
| IR Light Control |
Smart IR (Auto/Manual)/OFF |
| IR Light Number |
2 |
| Day/Night |
Auto/Day/Night/Schedule |
| Backlight Compensation |
WDR, HLC |
| White Balance |
Auto/Fixed Current/Manual |
| Gain Control |
0-100% |
| Wide Dynamic Range |
120dB |
| Noise Reduction |
3D DNR |
| Privacy Masking |
Off / On (5 Areas) |
| Motion Detection |
Motion/Intrusion/People detection |
| Tampering Detection |
Tampering Detection/Image too dark
detection/Image too bright detection/
Image too blurry detection |
| Region Of Interest |
Support |
| Lens |
4.0mm, Fixed, F2.0 |
| Angle Of View |
HC30WE5R3: H:103°, V:76° @5M
HC30WE5R3: H:108°, V:60° @4M |
| VIDEO |
|
| Video Compression |
H.265/H.264/Smart Codec/MJPEG |
| Resolution |
HC30WE5R3 (5MP):
2560×1920/2048×1536/
1600×1200/1280×960/800×600/640×480;
HC30WE5R3 (4MP):
2688×1520/1920×1080/
1600×904/1280×720/640×36 |
| Frame Rate |
HC30WE5R3:
Main Stream: 5M/4M (1 ~ 25/30fps);
*Up to 30fps @5M under H.265 only
Sub Stream: 800×600 (1 ~ 25/30fps);
Third Stream: VGA (1 ~ 25/30fps) |
| Bit Rate Control |
Constrained bit rate/Fixed quality |
| Bit Rate |
20K ~ 40Mbps |
| NETWORK |
|
| Ethernet |
10 Base-T/100 Base-TX Ethernet (RJ-45) |
| Supported Web Browsers |
Chrome 71+, Internet Explorer 11.0+ |
| Supported OS |
Microsoft Windows 7/10 |
| Protocols* |
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP,
RTSP/RTP/RTCP, IGMP, SMTP, DHCP, NTP,
DNS, DDNS, CoS, QoS, SNMP, 802.1X,
UDP, ICMP, ARP, TLS |
| Interoperability |
ONVIF Profile G/S |
| Maximum Users Access |
10 Users |
| Security |
User account and password protection,
HTTPS, IP Filter, Digest authentication,
TLS1.2 only, Stream encryption, AES128/256, SSH/ Telnet closed, PCIDSS
compliance |
| Event |
Event notification using HTTP, SMTP, NAS
server and MicroSD card
File upload via HTTP, SMTP, NAS server
and MicroSD card |
| Micro SD |
Micro SD/SDHC/SDXC card slot (256GB) |
| ELECTRICAL |
|
| Power Supply |
DC12V, PoE (IEEE 802.3af) (Class 2 |
| Power Consumption |
MAX 6.49W |
| MECHANICAL |
| Dimensions |
ø91.1mm x 177mm (ø3.59” x 6.97’’) |
| Product Weight |
0.53kg |
| Package Weight |
0.74kg |
| Material |
Die-casting aluminum housing with
coating |
| Construction Color |
RAL 120-1 (Lyric White) |
| ENVIRONMENTAL |
| Operating Temperature |
Starting: -10°C ~ 60°C (14°F ~ 140°F)
Working: -30°C ~ 60°C (-22°F ~ 140°F |
| Relative Humidity |
Less than 90%, non-condensing |
| Ingress Protection |
IP66 |
| REGULATORY |
| Emissions |
FCC PART 15B, EN 55032, EN61000-6-3 |
| Immunity |
EN 50130-4 |
| Safety |
UL 62368-1, EN 62368-1 |
| ROHS |
EN 50581 |
| SYSTEM COMPATIBILITY* |
| MAXPRO NVR PE |
Up to 128 IP channels RAID5/6 Enterprise NVR |
| MAXPRO NVR SE |
Up to 64 IP channels System NVR |
| MAXPRO NVR SOFTWARE |
Up to 128 IP channels Recording Software |
| MAXPRO NVR XE |
Up to 16 IP channels system NVR |
| ADPRO NVR FASTTRACE 2E |
Up to 32 IP channels with up to 32 VA channels NVRs, or Up to
20 Analogue channels Hybrids |
| ADPRO NVR IFT-E |
Up to 32 IP channels with up to 32 VA channels NVR |
| ADPRO NVR IFT |
Up to 32 IP channels or 16 IP channels with up to 16 VA
channels NVRs |
| ADPRO NVR EFT |
Up to 16 IP channels with up to 8 VA channels NVRs, or Up to
16 Analogue channels Hybrids |
| ADPRO NVR IFT GATEWAY |
4 IP channels + 4 VA channels |
| HEN*4 |
8/16/32/64-channel Performance Series NVRs (H.264 and
H.265) |
| HEN*3 |
4/8/16-channel Performance Series NVRs (H.264 and H.265) |
| HONEYWELL DVM |
Supported with Honeywell DVM R700.1 SP1 (and later
maintenance releases) |
| 30 SERIES NVRS |
8/16-channel 30 Series NVRs (4K/ H.264 and H.265) |
