Paxton 371-210 Compact Touchlock Keypad K75 – Single Door Access Control
Paxton 371-210 K75 compact touchlock keypad for standalone single door access control. Supports up to 50 codes, lockout function, and adjustable door timing.
- Description
- Technical Specification
Description
The Paxton 371-210 Compact Touchlock Keypad K75 is a reliable and stylish single door access control solution, designed for simple and secure standalone operation. All electronics are housed within the unit, making installation fast and cost-effective.
The K75 keypad supports 4–8 digit codes, with a capacity of up to 50 unique user codes. For enhanced protection, it includes an optional 20-digit lockout feature. Door open time is fully adjustable between 1 and 60 seconds, providing flexibility for different security needs.
Supplied with a durable black bezel, this model offers a professional finish. Replacement bezels are also available in black or white/grey and can be obtained free of charge by Paxton registered installers.
Installation is straightforward, requiring two wires to connect to the lock, two to the power supply, and optional connections for an exit button. A centrally positioned rear cable exit allows precise and neat mounting. Additionally, the K75 keypad includes connections for an external sounder, enabling the ‘bell’ key to be used as a doorbell.
Programming and code management are completed directly via the keypad using the master code, ensuring easy operation and minimal maintenance.
Key Features
- Paxton 371-210 Compact K75 touchlock keypad
- Standalone single door access control system
- Up to 50 user codes (4–8 digits)
- Optional 20-digit lockout for added security
- Adjustable door open time (1–60 seconds)
- Supplied with black bezel (replacement bezels available)
- External sounder connection for doorbell function
- Easy master code programming for all settings
Applications
- Offices and commercial buildings
- Schools and universities
- Retail and hospitality venues
- Healthcare facilities
- Secure entry points for internal and external doors
| Specification | Details |
|---|---|
| Brand | Paxton |
| Model Number | 371-210 (K75) |
| System Type | Compact standalone keypad |
| Access Method | 4–8 digit codes |
| User Capacity | Up to 50 codes |
| Lockout Option | Optional 20-digit lockout |
| Door Open Time | Adjustable 1–60 seconds |
| Finish / Bezel | Black bezel (white/grey available) |
| Installation | 2 wires to lock, 2 wires to power supply |
| Additional Features | Exit button connection, doorbell sounder option |
