Description

About – The Paxton 411-623 Net2 I/O Board provides four inputs and four mains-rated relay outputs for integration with building systems such as lifts, lighting, heating, and HVAC. It connects directly to a LAN/WAN via an onboard RJ45 connector, allowing flexible distribution throughout a building. Inputs and outputs are easily controlled via the Net2 software using the triggers and actions feature. The board is available as PCB only, in a protective plastic housing, or mounted within a 2A boxed metal/plastic mains monitored backup power supply.

Installation – The I/O board connects directly to the network using the onboard RJ45 connector. A clearly marked label shows all connections, and rising clamp connectors (as used on Net2 control units) ensure secure wiring and straightforward setup.

Operation – Once installed, inputs and outputs can be configured within the Net2 software. Using the triggers and actions feature, the board automates building functions such as lighting, heating, lifts, and security responses to system events.

Key Features

• 4 inputs and 4 mains-rated relay outputs per board
• Connects directly to LAN/WAN via onboard RJ45 connector
• Controlled through Net2 software triggers and actions
• Supports integration with lifts, lighting, heating, HVAC, and security systems
• Flexible supply options: PCB only, plastic housing, or metal/plastic backup PSU
• Designed for distributed installation around buildings

Applications

• Access control integration with building management systems
• Multi-site or large-scale Net2 projects
• Automated control of lifts, lighting, and heating systems
• Enhanced building security and smart automation
