Samsung SCV-6023R 1080p Full HD Vandal-Resistant IR Dome Camera 4mm Lens, IP66, IK10 Vandal-Proof
£39.99
This Full HD camera delivers clear 1080p video at 30fps, even in low light with 0.25Lux in color and 0Lux in black and white (IR LEDs on). It features a 4mm fixed lens, 20m IR range, and reliable Day & Night performance with motion detection. With an IP66 weatherproof rating and IK10 impact resistance, it’s built to last in tough environments and offers easy plug-and-play installation with up to 500m transmission range.
- Description
- Technical Specification
Description
Key Features
- Shoots in Full HD 1080p at 30fps, so everything looks sharp and detailed.
- Works well in low light — shows colour in dim conditions and switches to black & white when it’s dark, thanks to built-in infrared.
- Comes with a 4mm fixed lens, giving you a nice, wide view of the area.
- Automatically switches between day and night mode, and has tech like DWDR and noise reduction to keep the image clear.
- Night vision range is up to 20 metres, so it doesn’t miss anything even in complete darkness.
- Built to handle the elements — IP66 weatherproof and IK10 vandal-resistant, great for outdoor use.
- Can transmit footage up to 500m, which gives you more flexibility on where to place it.
- Super easy to install — just plug it in and it’s ready to go.
| Video | |
|---|---|
| Imaging Device | 1/3″ 2MP CMOS |
| Resolution | 1920×1080 |
| Max. Framerate | 30fps |
| Min. Illumination | Color: 0.25Lux(F2.1) BW: 0.0Lux(IR LED on) |
| Video Out | BNC(AHD / CVBS selectable) |
| Video Transmission Distance | 500m(75-5 coaxial cable) |
| Lens | |
| Focal Length (Zoom Ratio) | 4mm fixed focal |
| Max. Aperture Ratio | F2.1 |
| Angular Field of View | H: 80.7° / V: 43.5° / D: 95.8° |
| Min. Object Distance | 0.5m(1.64ft) |
| Focus Control | Manual |
| Pan / Tilt / Rotate | |
| Pan / Tilt / Rotate Range | 0°~350° / 0°~67° / 0°~355° |
| Operational | |
| Camera Title | Displayed up to 15 characters |
| Day & Night | Auto(ICR) |
| Backlight Compensation | UserBLC, HLC, DWDR |
| Digital Noise Reduction | SSNRⅣ |
| Defog | Support |
| Motion Detection | 4ea |
| Privacy Masking | 4ea, rectangular zones |
| Gain Control | Low / Midel / High |
| White Balance | ATW / AWC / Manual / Indoor / Outdoor |
| Electronic Shutter Speed | 1 ~ 1/12,000sec |
| Video Rotation | H-Rev / V-Rev |
| Analytics | Motion detection |
| IR Viewable Length | 20m(65.62ft) |
| Coaxial Protocol | ACP(AHD Coax Protocol) CVBS: Pelco-C(Coaxitron) |
| Environmental & Electrical | |
| Operating Temperature / Humidity | -30°C ~ +55°C (-22°F ~ +131°F) / Less than 90% RH *Start up should be done at above -10°C (+14°F) |
| Certification | IP66, IK10, Safety(UL), EMC(FCC, CE) |
| Input Voltage | 12VDC |
| Power Consumption | Max 4.2W |
| Mechanical | |
| Color / Material | Ivory / Aluminum |
Model No- SCV-6023R
